XM-18D Incubator Controller Thermostat

XM-18D incubator controller with 7 outputs, adjustable egg turning, high-precision temperature & humidity sensors, and 6 incubation modes. Ideal for chicken, duck, goose and pigeon incubators.

The XM-18D Automatic Incubator Controller is a powerful, microcomputer-based control system designed for modern poultry incubators. Whether you are assembling incubators locally, upgrading an existing unit or replacing a faulty controller, the XM-18D provides unmatched accuracy, stability and advanced customization for optimal hatch results.

Using a high-precision temperature sensor and a stable humidity sensor, the XM-18D maintains perfect incubation conditions for all poultry species. It includes 6 incubation modes (user-defined, chicken, duck, goose and others) and offers complete control over temperature, humidity, ventilation cycles, and egg turning.

With 7 signal outputs, the controller manages all essential incubator functions including heating, humidification, ventilation, alarms and left/right egg turning motors.

This is the same controller used in many imported incubators and is also a key component that Autohatch uses when assembling local incubators.

KEY FEATURES & BENEFITS
🔁 Adjustable Egg Turning (0–999 min)
Full automatic egg turning interval control

Adjustable from 0 to 999 minutes

Ensures even embryo development and higher hatch rates

🐣 Multi-Mode Incubation System
6 preset modes for various poultry types

Includes chicken, duck, goose, pigeon, and custom settings

📟 Advanced Digital Display
Four separate screens

Shows real-time temperature, humidity, incubation days and turn count

🎯 High-Precision Sensors
Temperature accuracy ±0.1°C

Humidity accuracy ±3% RH

Stable microcomputer chip with strong anti-interference performance

🚨 Full Alarm & Protection System
7 signal outputs including:
✔ Over-temperature
✔ Temperature control
✔ Low temperature
✔ Humidity control
✔ Left turn
✔ Right turn
✔ Global alarm

🌀 Ventilation Control
Adjustable ventilation cycle and duration

Ensures proper oxygen exchange during incubation

⚡ Wide Voltage Range
Works reliably between AC 160–240V

Protects against voltage fluctuations common in rural areas

💼 Ideal for Builders & Repair Shops
Perfect for:

New incubator assembly

Upgrading old analog controllers

Replacing faulty control boards

Custom DIY incubators

TECHNICAL SPECIFICATIONS
Parameter Value
Model XM-18D
Size 300 × 83 × 120 mm
Temperature Range 0–99.9°C
Temperature Accuracy ±0.1°C
Humidity Range 0–99% RH
Humidity Accuracy ±3% RH
Egg Turning Cycle 0–999 minutes (Default: 90 min)
Egg Turning Duration 0–999 seconds (Default: 180 sec)
Ventilation Cycle 0–999 minutes
Ventilation Duration 0–999 seconds
Max Egg Turn Count 999 turns
Sensor Cable Length 1.5 meters
Signal Outputs 7
Working Voltage AC 160V–240V, 50Hz
Working Humidity ≤85% RH
